| Accuracy | T7 |
|---|---|
| Ball Circle Diameter (in) | 1.000 |
| Ball Screw Length | 31.00 |
| Ball Nut PN | HBN1052 |
| Ball Nut Weight (lbs) | 1.2 |
| Ball Screw Weight (lb/ft) | 2.2 |
| Balls per Circuit | 86 |
| Balls per Nut | 172 |
| Circuits | 2 |
| Code | 0023 |
| Dynamic Load (lbs) for 1M (in) | 3443 |
| End 2 | 00 |
| Lead (in) | 0.500 |
| Lead Time | 2 Weeks |
| Material | Alloy |
| Max Static Load (lbs) | 25260 |
| Preloaded Y/N | no |
| Thread Direction | RH |
