Motor Mount for Flanged Bearing Mount, EZF-1008-17 | Helix Linear Technologies

Diagram
Specifications

A (in)	1.75
A (mm)	44.45
Acme Screw Diameter - (in)	0.5
B (in)	2.84
B (mm)	72.14
Ball Screw Diameter - (in)	0.5
C (in)	2.2
C (mm)	55.88
D (in)	0.52
D (mm)	13.21
E (in)	–
E (mm)	–
EZZE Mount	EZF-1008
F (in)	0.25
F (mm)	6.35
G (in)	0.25
G (mm)	6.35
H (in)	0.094
H (mm)	2.39
J (in)	.871+0-.003
J (mm)	22.12+0-0.08
K (in)	1.725
K (mm)	43.82
Lead Time	2 Weeks
NEMA Frame	17
