Motor Mount for Universal Bearing Mount, EZM-2020-34 | Helix Linear Technologies

Diagram
Specifications

A (in)	3.44
A (mm)	87.4
Acme Screw Diameter - (in)	1.125
B (in)	5.96
B (mm)	151.4
Ball Screw Diameter - (in)	1
C (in)	3.44
C (mm)	87.38
D (in)	0.81
D (mm)	20.574
E (in)	0.1
E (mm)	2.54
EZZE Mount	EZM-2020
F (in)	0.16
F (mm)	4.064
G (in)	0.5
G (mm)	12.7
H (in)	0.125
H (mm)	3.18
J (in)	2.882+0-.004
J (mm)	73.20?0-0.10
K (in)	3.875
K (mm)	98.43
Lead Time	2 Weeks
NEMA Frame	34
