Dynamic Load (N)7800, 9150, 6700, 1753, 1506.22
Dynamic Load (lbs)1753.51, 2057, 1506, 7800, 6700
E (mm)2.5 mm, 12 mm, 19 mm, 10 mm
F (mm)4 mm, 5.5 mm
FP9 (mm)4 mm
G (mm)16 mm, 38 mm, 42 mm
H (thread)M26x1.5, M33x1.5
J (mm)10 mm
K (mm)10 mm
M (mm)ø3 mm, ø4 mm, 4 mm
Maximum Standard Backlash (mm)0.07, 0.0028
Number of Ball Circulations2x1.9, 3x1.5, 2x1.6
Nut StyleCylindrical, Threaded, Rectangular Flanged, Round Flanged
Nut TypeBall Nut
Size16x16
Static Load (N)15500, 18750, 13700, 3484, 3079.88
Wiper CodeS, N
WipersYes, No
