Dynamic Load (N)21000, 14100, 4720, 3169.81
Dynamic Load (lbs)4720, 3169, 21000, 14100
E (mm)19 mm, 10 mm
F (mm)4 mm, 6.6 mm
G (mm)55 mm, 53 mm
H (thread)M40x1.5, M45x1.5
J (mm)10 mm
K (mm)7 mm, 10 mm
M (mm)ø4 mm, M6 mm, 4 mm
Maximum Standard Backlash (mm)0.0028
Number of Ball Circulations2x2.5, 2x2.7
Nut StyleThreaded, Rectangular Flanged, Round Flanged
Nut TypeBall Nut
Size25x10
Static Load (N)54000, 39800, 12139, 8947.4
Wiper CodeS, N
WipersYes, No
