Dynamic Load (lbs)314.73, 1400
E (mm)2 mm, 4 mm
F (mm)3.4 mm
FP9 (mm)2 mm
G (mm)8 mm, 25 mm
J (mm)6 mm
K (mm)4 mm
M (mm)ø2 mm
Maximum Standard Backlash (mm)0.05, 0.002
Number of Ball Circulations2x1.5
Nut StyleCylindrical, Rectangular Flanged
Nut TypeBall Nut
Size8x12
Static Load (N)2300, 517
Wiper CodeS
WipersYes
