Dynamic Load (N)1500, 2000, 449.62
Dynamic Load (lbs)337, 449, 2000
E (mm)8 mm, 10 mm, 4 mm
F (mm)2.5 mm, 3.4 mm
G (mm)28 mm
H (thread)M14x1, M20x1
J (mm)5 mm
K (mm)4 mm
M (mm)ø2 mm, 2 mm
Maximum Standard Backlash (mm)0.0024, 0.002
Number of Ball Circulations2x1.5, 2x1.7
Nut StyleThreaded, Round Flanged
Nut TypeBall Nut
Size8x8
Static Load (N)2500, 3700, 831.79
Wiper CodeN, S
WipersNo, Yes
