accuracy7
Ball Circle Diameter (in)0.631
Ball Circle Diameter (mm)16.0274
Ball Screw Length10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 6, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 7, 70, 71, 72, 8, 9
Ball Screw Weight (lb/ft)0.81
Code7
Dynamic Load (lbs) for 1M (in)743, 141
End 20
Max Static Load (lbs)6168, 1150
Related DoubleHBN6313
Related SingleHBN6311
Related Single SSHBN6312
Torque to Raise 1 lb (in-lb)0.035
