accuracy7
Ball Circle Diameter (in)0.75
Ball Circle Diameter (mm)19.050
Ball Screw Length10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 6, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 7, 70, 71, 72, 8, 9
Ball Screw Weight (lb/ft)1.2
Code14
Dynamic Load (lbs) for 1M (in)1105
End 20
Max Static Load (lbs)8571
Related DoubleHNB7502
Related SingleHBN7501
Torque to Raise 1 lb (in-lb)0.035
