accuracy7
Ball Circle Diameter (in)1
Ball Circle Diameter (mm)25.4
Ball Screw Length10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 6, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 7, 70, 71, 72, 8, 9
Ball Screw Weight (lb/ft)1.22
Code22
Dynamic Load (lbs) for 1M (in)291
End 20
Max Static Load (lbs)2506
Related DoubleHBN1003
Related Double SSHBN1003
Related SingleHBN1001
Torque to Raise 1 lb (in-lb)0.044
