accuracy7
Ball Circle Diameter (in)1
Ball Circle Diameter (mm)25.4
Ball Screw Length10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 6, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 7, 70, 71, 72, 8, 9
Ball Screw Weight (lb/ft)2.2
Code24
Dynamic Load (lbs) for 1M (in)2071
End 20
Max Static Load (lbs)11650
Related DoubleHBN1102
Torque to Raise 1 lb (in-lb)0.177
