Nut CodeNFA
Connection TypeFlanged
D - Flange Diameter (in)1.5
Diameter Code50
Efficiency (%)78.6085705
F - Flange Thickness (in)0.25
G - Slot Width (in)0.203
H - Bolt Circle Diameter (in)1.125
Mating Screw Part No050500L, 050500R
Nut Diameter B (in)0.75
Nut Length C (in)1.125
Nut TypeStandard nut with mounting flange
Nut Weight (lb)0.04
Standard Operating Temperature Range (F°)32-200
Torque to Raise 1 lb (in-lb)0.1012325641
