Nut CodeNTA
Connection TypeThreaded
D - Thread Size (in)5/8-18 UNF
Diameter Code37
Dynamic Load Capacity (lb)75.00
E - Thread Length (in)0.25
Efficiency (%)82.64351221
F - Hex Across Flats (in)0.625
Flange Part No - RoundHF37
Flange Weight (lb)0.04
G - Hex Thickness (in)0.18
Mating Screw Part No037M38R, 037M38L
Nut Diameter B (in)0.625
Nut Length C (in)0.75
Nut Size3
Nut TypeStandard nut with mounting threads
Nut Weight (lb)0.02
Standard Operating Temperature Range (F°)32-200
Torque to Raise 1 lb (in-lb)0.2888701221
