Nut CodeNTA
Connection TypeThreaded
D - Thread Size (in)15/16-16 UN
Diameter Code47
Dynamic Load Capacity (lb)150.00
E - Thread Length (in)0.375
Efficiency (%)41.54504972
F - Hex Across Flats (in)1
Flange Part No - RoundHF50
Flange Weight (lb)0.08
G - Hex Thickness (in)0.25
Mating Screw Part No047078L, 047078R
Nut Diameter B (in)0.75
Nut Length C (in)1.125
Nut Size4
Nut TypeStandard nut with mounting threads
Nut Weight (lb)0.04
Standard Operating Temperature Range (F°)32-200
Torque to Raise 1 lb (in-lb)0.0301491853
