Nut CodeSNA
Diameter Code125
Dynamic Load Capacity (lb)3950
Efficiency (%)40.4565681
Mating Screw Part No125200L, 125200R
Nut Diameter B (in)2
Nut Length C (in)2.5
Nut TypeSleeve Nut
Standard Operating Temperature Range (F°)32 - 200
Static Load Capacity (lb)6300.00
Torque to Raise 1 lb (in-lb)0.0786794088
