D1 (in)0.43 in
D1 (mm)10.922 mm
D2 (in)0.38 in
D2 (mm)9.652 mm
D3 (in)1 in
D3 (mm)25.4 mm
D4 (in)0.5 in
D4 (mm)12.7 mm
Diameter Code25
Diameter D (in)0.25
Diameter D (mm)6.35
E (in)1.35 in
E (mm)34.29 mm
EncoderNo Encoder, 1000 CPR
F (in)1.94 in
F (mm)49.276 mm
Fy - Axial Static Load Capacity (lbs)150.00
Fz - Dynamic Normal Load (lbs)856.50
Fz - Static Normal Load (lbs)1,256.70
G4-40 UNC-2B
G1 (in)0.22 in
G1 (mm)5.588 mm
H (in)1.75 in
H (mm)44.45 mm
Inductance/Phase (mH)1.1
J (in)1.52 in
J (mm)38.608 mm
K (in)0.63 in
K (mm)16.002 mm
K1 (in)0.36 in
K1 (mm)9.144 mm
K2 (in)0.16 in
K2 (mm)4.064 mm
K3 (in)1.06 in
K3 (mm)26.924 mm
L (in)4.6 in
L (mm)116.84 mm
Length Adder (in)2.6
Length Adder (mm)66.04
Motor Size (NEMA)11, 17, 23
Motor StackDouble Stack, Single Stack
Motor Voltage (V)2.1, 5, 2.33, 3.25
Motor Weight (g)180
Motor Weight (oz)6.3, 4.2, 12.4, 8.5, 33.8, 18
Mx - Maximum Moment Load (in/lbs)239.00
My - Maximum Moment Load (in/lbs)386.00
Mz - Maximum Moment Load (in/lbs)239.00
N (in)1.21 in
N (mm)30.734 mm
Nut TypeAxial Anti-backlash Nut, Standard Freewheeling Nut
P (in)1.26 in
P (mm)32.004 mm
Power Consumption (W)7.5
Profile Rail Linear Actuator Catalogprofile_rail_linear_guidance_system.pdf
Q1 (in)1.22 in
Q1 (mm)30.988 mm
Q (in)1.22 in
Q (mm)30.988 mm
R (in)2.34 in
R (mm)59.436 mm
Rated Current (A)1.9, 0.75, 1, 0.42, 2.6, 1.3, 1.5, 0.7, 3.32, 2.16, 2
S (in)1.52 in
S (mm)38.608 mm
Screw Drive TypeLead Screw
T1 (in)1.35 in
T1 (mm)34.29 mm
T (in)1.16 in
T (mm)29.464 mm
Temperature Rise (°C)75
Travel (in)2
Travel (mm)50.8
Travel Per Step (in)0.000625
Travel Per Step (mm)0.015875
U (in)0.65 in
U (mm)16.51 mm
V (in)0.75 in
V (mm)19.05 mm
W (in)1.575 in
W (mm)39.878 mm
WiringBipolar
Wiring Leads4
X (in)1.26 in
X (mm)32.004 mm
Y (in)0.13 in
Y (mm)3.302 mm
Zero Lash Axial Dynamic Load Capacity (lb)5.00
