Nut CodeNTA
Connection TypeThreaded
D - Thread Size (in)9/16-18 UNF
Diameter Code25
Dynamic Load Capacity (lb)75.00
E - Thread Length (in)0.25
Efficiency (%)82.36895239
F - Hex Across Flats (in)0.625
Flange Part No - RoundHF25
Flange Weight (lb)0.02
G - Hex Thickness (in)0.18
Mating Screw Part NoRD025999L, RD025999R
Nut Diameter B (in)0.5
Nut Length C (in)0.625
Nut Size2
Nut TypeStandard nut with mounting threads
Nut Weight (lb)0.02
Standard Operating Temperature Range (F°)32-200
Torque to Raise 1 lb (in-lb)0.1932220072
